SERIE
SERRATURE PER PORTE BLINDATE LINE 166C BASIC GEAR/
SAFETY DOOR LOCKS Y G TOP GEAR

Serrature SOLO CATENACCIO GEAR “Serie 166C”, ambidestre, per porte blindate a Locks ONLY LATCH GEAR “Line 166C” for European cylinder safety doors, ambidextrous.
cilindro europeo. Triple lock with gear movement, stroke 30 mm and latch. ONLY BOLT , NO LATCH
Chiusura triplice con movimento ad ingranaggi, corsa 30 mm SOLO CATENACCIO SENZA Galvanized finish with bolts Ø 18 mm in chromed steel.
SCROCCO. Through-holes interspace 38 mm for protector fixing
Finitura zincata con catenacci Ø18 mm in acciaio cromato. Planar, lateral on request or mortice fixing with frontal in stainless steel 350x35x3 mm.
Fori passanti interasse 38 mm per fissaggio Protector. Cylinder fixing “C” with Securemme tab or “T” with head-screw.
Fissaggio serratura planare, a richiesta laterale o ad infilare con frontale in acciaio inox Available in BASIC GEAR or TOP GEAR version with double SECURTINA block and
350x35x3 mm. reinforcement against bolt-push over 1000 kg.
Fissaggio cilindro “C” con attacco Securemme oppure con “T” con vite in testa
Disponibili nelle versioni BASIC GEAR o TOP GEAR con doppia trappola SECURTINA e
rinforzo alla spinta catenaccio maggiore di 1000 kg.

C
P R T

PLANARE | PLANAR 1661SCR0328TXX INFILARE FRONTALE INOX | MORTICE INOX FRONTAL 1663SCR0328TXX

FRONTALE INOX
INOX FRONTAL

T T

S - Sporgenza pistoni | Projection bolts
FISSAGGIO PLANARE | PLANAR FIXING I - Interasse | Interspace
BASIC GEAR TOP GEAR BASIC GEAR TOP GEAR
C
g g g g
Y T T Y S I
166 1 SCR0328TXX 1930 166 1 SCR0328TT2 2070 166 1 SCR0328CXX 1980 166 1 SCR0328CT2 1930 3 mm 28 mm 5
166 1 SCR0337TXX 1840 166 1 SCR0337TT2 1840 166 1 SCR0337CXX 1750 166 1 SCR0337CT2 1840 3 mm 37 mm 5
166 1 SCR0628TXX 1955 166 1 SCR0628TT2 1980 166 1 SCR0628CXX 1890 166 1 SCR0628CT2 1955 6 mm 28 mm 5
166 1 SCR0637TXX 1860 166 1 SCR0637TT2 2000 166 1 SCR0637CXX 1910 166 1 SCR0637CT2 1860 6 mm 37 mm 5
166 1 SCR1328TXX 2030 166 1 SCR1328TT2 2170 166 1 SCR1328CXX 2080 166 1 SCR1328CT2 2030 13 mm 28 mm 5
166 1 SCR1337TXX 2020 166 1 SCR1337TT2 2160 166 1 SCR1337CXX 2070 166 1 SCR1337CT2 2020 13 mm 37 mm 5
166 1 SCR2328TXX 2130 166 1 SCR2328TT2 2270 166 1 SCR2328CXX 2180 166 1 SCR2328CT2 2130 23 mm 28 mm 5
166 1 SCR2337TXX 2000 166 1 SCR2337TT2 2140 166 1 SCR2337CXX 2000 166 1 SCR2337CT2 2000 23 mm 37 mm 5
166 1 SCR3328TXX 2230 166 1 SCR3328TT2 2370 166 1 SCR3328CXX 2250 166 1 SCR3328CT2 2230 33 mm 28 mm 5
166 1 SCR3337TXX 2080 166 1 SCR3337TT2 2220 166 1 SCR3337CXX 2130 166 1 SCR3337CT2 2080 33 mm 37 mm 5
166 1 SCR4328TXX 2330 166 1 SCR4328TT2 2470 166 1 SCR4328CXX 2380 166 1 SCR4328CT2 2330 43 mm 28 mm 5
166 1 SCR4337TXX 2160 166 1 SCR4337TT2 2300 166 1 SCR4337CXX 2210 166 1 SCR4337CT2 2160 43 mm 37 mm 5

FISSAGGIO AD INFILARE FRONTALE INOX | MORTICE FIXING INOX FRONTAL
166 3 SCR0328TXX 2180 166 3 SCR0328TT2 2210 166 3 SCR0328CXX 2230 166 3 SCR0328CT2 2180 3 mm 28 mm 5
166 3 SCR0337TXX 2090 166 3 SCR0337TT2 1980 166 3 SCR0337CXX 2000 166 3 SCR0337CT2 2090 3 mm 37 mm 5
