SERRATURE PER PORTE BLINDATE SERIE 251
SAFETY DOOR LOCKS S LINE SECURMAP 24

SOLO CATENACCIO, SENZA SCROCCO ONLY BOLT, NO LATCH
Serratura con cuore intercambiabile a doppia mappa 4 mandate corsa 40 mm, senza Security lock with interchangeable double ward heart, 4 turns, bolts stroke 40 mm, no
scrocco, chiusura triplice. latch and 3 locking points.
Finitura zincata con catenacci in acciaio cromato. Galvanized finishing with bolts in chromed steel.
Duplicazione chiave protetta. Protected key duplication.

BREVETTI | PATENTED Soddisfano la classe 7 (min 1 - max 7) secondo la norma
UNI ENV 12209:2005 in abbinamento alla piastra di protezione.
B P X According to UNI ENV 12209:2005 it meets class 7 (min 1 - max 7);
in combination with protection plate.

FISSAGGIO PLANARE/LATERALE | PLANAR/LATERAL FIXING

3+1T chiavi/keys 5 +1T chiavi/keys
Apertura porta/Opening door Apertura porta/Opening door
Sporgenza Interasse
D R S L g D R S L g pistoni (S) Interspace
Projection
* * * * bolts (S) *
251 1 DCR0328S46 251 1 SCR0328S46 2250 251 1 DCR0328S47 251 1 SCR0328S47 2300 3 mm 28 mm 40 mm 5
251 1 DCR0328S56 251 1 SCR0328S56 2270 251 1 DCR0328S57 251 1 SCR0328S57 2320 3 mm 28 mm 50 mm 5
251 1 DCR0328S66 251 1 SCR0328S66 2290 251 1 DCR0328S67 251 1 SCR0328S67 2340 3 mm 28 mm 65 mm 5
251 1 DCR0628S46 251 1 SCR0628S46 2300 251 1 DCR0628S47 251 1 SCR0628S47 2350 6 mm 28 mm 40 mm 5
251 1 DCR0628S56 251 1 SCR0628S56 2320 251 1 DCR0628S57 251 1 SCR0628S57 2370 6 mm 28 mm 50 mm 5
251 1 DCR0628S66 251 1 SCR0628S66 2340 251 1 DCR0628S67 251 1 SCR0628S67 2390 6 mm 28 mm 65 mm 5
251 1 DCR1328S46 251 1 SCR1328S46 2398 251 1 DCR1328S47 251 1 SCR1328S47 2448 13 mm 28 mm 40 mm 5
251 1 DCR1328S56 251 1 SCR1328S56 2418 251 1 DCR1328S57 251 1 SCR1328S57 2468 13 mm 28 mm 50 mm 5
251 1 DCR1328S66 251 1 SCR1328S66 2488 251 1 DCR1328S67 251 1 SCR1328S67 2488 13 mm 28 mm 65 mm 5
251 1 DCR4328S46 251 1 SCR4328S46 2762 251 1 DCR4328S47 251 1 SCR4328S47 2812 43 mm 28 mm 40 mm 5
251 1 DCR4328S56 251 1 SCR4328S56 2782 251 1 DCR4328S57 251 1 SCR4328S57 2832 43 mm 28 mm 50 mm 5
251 1 DCR4328S66 251 1 SCR4328S66 2802 251 1 DCR4328S67 251 1 SCR4328S67 2852 43 mm 28 mm 65 mm 5
251 1 DCR0337S46 251 1 SCR0337S46 2150 251 1 DCR0337S47 251 1 SCR0337S47 2200 3 mm 37 mm 40 mm 5
251 1 DCR0337S56 251 1 SCR0337S56 2170 251 1 DCR0337S57 251 1 SCR0337S57 2220 3 mm 37 mm 50 mm 5
251 1 DCR0337S66 251 1 SCR0337S66 2190 251 1 DCR0337S67 251 1 SCR0337S67 2240 3 mm 37 mm 65 mm 5
251 1 DCR0637S46 251 1 SCR0637S46 2200 251 1 DCR0637S47 251 1 SCR0637S47 2250 6 mm 37 mm 40 mm 5
251 1 DCR0637S56 251 1 SCR0637S56 2220 251 1 DCR0637S57 251 1 SCR0637S57 2270 6 mm 37 mm 50 mm 5
251 1 DCR0637S66 251 1 SCR0637S66 2240 251 1 DCR0637S67 251 1 SCR0637S67 2290 6 mm 37 mm 65 mm 5
251 1 DCR1337S46 251 1 SCR1337S46 2298 251 1 DCR1337S47 251 1 SCR1337S47 2348 13 mm 37 mm 40 mm 5
251 1 DCR1337S56 251 1 SCR1337S56 2318 251 1 DCR1337S57 251 1 SCR1337S57 2368 13 mm 37 mm 50 mm 5
251 1 DCR1337S66 251 1 SCR1337S66 2338 251 1 DCR1337S67 251 1 SCR1337S67 2389 13 mm 37 mm 65 mm 5
251 1 DCR4337S46 251 1 SCR4337S46 2662 251 1 DCR4337S47 251 1 SCR4337S47 2712 43 mm 37 mm 40 mm 5
251 1 DCR4337S56 251 1 SCR4337S56 2682 251 1 DCR4337S57 251 1 SCR4337S57 2732 43 mm 37 mm 50 mm 5
251 1 DCR4337S66 251 1 SCR4337S66 2702 251 1 DCR4337S67 251 1 SCR4337S67 2752 43 mm 37 mm 65 mm 5

FRONTALE INOX
FISSAGGIO AD INFILARE FRONTALE INOX | MORTICE FIXING INOX FRONTAL INOX FRONTAL

2513 D CR0328S46 2513 S CR0328S46 2710 2513 D CR0328S47 2513 S CR0328S47 2764 - 28 mm 40 mm 5
2513 D CR0328S56 2513 S CR0328S56 2734 2513 D CR0328S57 2513 S CR0328S57 2966 - 28 mm 50 mm 5
2513 D CR0328S66 2513 S CR0328S66 2754 2513 D CR0328S67 2513 S CR0328S67 2804 - 28 mm 65 mm 5
2513 D CR0337S46 2513 S CR0337S46 2614 2513 D CR0337S47 2513 S CR0337S47 2664 - 37 mm 40 mm 5
2513 D CR0337S56 2513 S CR0337S56 2634 2513 D CR0337S57 2513 S CR0337S57 2684 - 37 mm 50 mm 5
2513 D CR0337S66 2513 S CR0337S66 2654 2513 D CR0337S67 2513 S CR0337S67 2704 - 37 mm 65 mm 5

* Per ordinare l’articolo con mano R/L * Per ordinare l’articolo in confezione industriale
To order the R/L lock To order the lock in industrial packaging
2501 R CR0328S46 251 0 DCR0328S46
