SERRATURE PER PORTE BLINDATE SERIE 250
SAFETY DOOR LOCKS S LINE SECURMAP 24

Serratura con cuore intercambiabile a doppia mappa 4 mandate corsa 40 mm e scrocco Security lock with interchangeable double ward heart, 4 turns, bolts stroke 40 mm and
reversibile, chiusura triplice. reversible latch, 3 locking points.
Finitura zincata con catenacci in acciaio cromato. Galvanized finishing with bolts in chromed steel.
A serratura chiusa la maniglia non sgancia lo scrocco. When locked, the handle does not unhook the latch. It is possible to fix the handle
Possibilità fissaggio rosetta maniglia con viti passanti interasse 38 mm. escutcheon with 38 mm interspace through screw.
Duplicazione chiave protetta. Protected key duplication.

BREVETTI | PATENTED Soddisfano la classe 7 (min 1 - max 7) secondo la norma
UNI ENV 12209:2005 in abbinamento alla piastra di protezione.
B P R X According to UNI ENV 12209:2005 it meets class 7 (min 1 - max 7);
in combination with protection plate.

FISSAGGIO PLANARE/LATERALE | PLANAR/LATERAL FIXING

3+1T chiavi/keys 5 +1T chiavi/keys
Apertura porta/Opening door Apertura porta/Opening door
Sporgenza Interasse
D R S L g D R S L g pistoni (S) Interspace
Projection
* * * * bolts (S) *
250 1 D CR0328S46 250 1 S CR0328S46 2507 250 1 D CR0328S47 250 1 S CR0328S47 2559 3 mm 28 mm 40 mm 5
250 1 D CR0328S56 250 1 S CR0328S56 2509 250 1 D CR0328S57 250 1 S CR0328S57 2563 3 mm 28 mm 50 mm 5
250 1 D CR0328S66 250 1 S CR0328S66 2513 250 1 D CR0328S67 250 1 S CR0328S67 2519 3 mm 28 mm 65 mm 5
250 1 D CR0628S46 250 1 S CR0628S46 2530 250 1 D CR0628S47 250 1 S CR0628S47 2582 6 mm 28 mm 40 mm 5
250 1 D CR0628S56 250 1 S CR0628S56 2532 250 1 D CR0628S57 250 1 S CR0628S57 2586 6 mm 28 mm 50 mm 5
250 1 D CR0628S66 250 1 S CR0628S66 2536 250 1 D CR0628S67 250 1 S CR0628S67 2594 6 mm 28 mm 65 mm 5
250 1 D CR1328S46 250 1 S CR1328S46 2609 250 1 D CR1328S47 250 1 S CR1328S47 2661 13 mm 28 mm 40 mm 5
250 1 D CR1328S56 250 1 S CR1328S56 2613 250 1 D CR1328S57 250 1 S CR1328S57 2667 13 mm 28 mm 50 mm 5
250 1 D CR1328S66 250 1 S CR1328S66 2621 250 1 D CR1328S67 250 1 S CR1328S67 2679 13 mm 28 mm 65 mm 5
250 1 D CR4328S46 250 1 S CR4328S46 2980 250 1 D CR4328S47 250 1 S CR4328S47 3032 43 mm 28 mm 40 mm 5
250 1 D CR4328S56 250 1 S CR4328S56 2984 250 1 D CR4328S57 250 1 S CR4328S57 3036 43 mm 28 mm 50 mm 5
250 1 D CR4328S66 250 1 S CR4328S66 2986 250 1 D CR4328S67 250 1 S CR4328S67 3044 43 mm 28 mm 65 mm 5
250 1 D CR0337S46 250 1 S CR0337S46 2418 250 1 D CR0337S47 250 1 S CR0337S47 2470 3 mm 37 mm 40 mm 5
250 1 D CR0337S56 250 1 S CR0337S56 2420 250 1 D CR0337S57 250 1 S CR0337S57 2474 3 mm 37 mm 50 mm 5
250 1 D CR0337S66 250 1 S CR0337S66 2424 250 1 D CR0337S67 250 1 S CR0337S67 2482 3 mm 37 mm 65 mm 5
250 1 D CR0637S46 250 1 S CR0637S46 2441 250 1 D CR0637S47 250 1 S CR0637S47 2493 6 mm 37 mm 40 mm 5
250 1 D CR0637S56 250 1 S CR0637S56 2445 250 1 D CR0637S57 250 1 S CR0637S57 2499 6 mm 37 mm 50 mm 5
250 1 D CR0637S66 250 1 S CR0637S66 2453 250 1 D CR0637S67 250 1 S CR0637S67 2511 6 mm 37 mm 65 mm 5
250 1 D CR1337S46 250 1 S CR1337S46 2468 250 1 D CR1337S47 250 1 S CR1337S47 2520 13 mm 37 mm 40 mm 5
250 1 D CR1337S56 250 1 S CR1337S56 2472 250 1 D CR1337S57 250 1 S CR1337S57 2526 13 mm 37 mm 50 mm 5
250 1 D CR1337S66 250 1 S CR1337S66 2480 250 1 D CR1337S67 250 1 S CR1337S67 2538 13 mm 37 mm 65 mm 5
250 1 D CR4337S46 250 1 S CR4337S46 2781 250 1 D CR4337S47 250 1 S CR4337S47 2833 43 mm 37 mm 40 mm 5
250 1 D CR4337S56 250 1 S CR4337S56 2785 250 1 D CR4337S57 250 1 S CR4337S57 2839 43 mm 37 mm 50 mm 5
250 1 D CR4337S66 250 1 S CR4337S66 2793 250 1 D CR4337S67 250 1 S CR4337S67 2851 43 mm 37 mm 65 mm 5

FRONTALE INOX
FISSAGGIO AD INFILARE FRONTALE INOX | MORTICE FIXING INOX FRONTAL INOX FRONTAL

2503 D CR0328S46 2503 S CR0328S46 2760 2503 D CR0328S47 2503 S CR0328S47 2811 - 28 mm 40 mm 5
2503 D CR0328S56 2503 S CR0328S56 2862 2503 D CR0328S57 2503 S CR0328S57 2911 - 28 mm 50 mm 5
2503 D CR0328S66 2503 S CR0328S66 2962 2503 D CR0328S67 2503 S CR0328S67 3013 - 28 mm 65 mm 5
2503 D CR0337S46 2503 S CR0337S46 2690 2503 D CR0337S47 2503 S CR0337S47 2743 - 37 mm 40 mm 5
2503 D CR0337S56 2503 S CR0337S56 2792 2503 D CR0337S57 2503 S CR0337S57 2843 - 37 mm 50 mm 5
2503 D CR0337S66 2503 S CR0337S66 2892 2503 D CR0337S67 2503 S CR0337S67 2943 - 37 mm 65 mm 5

* Per ordinare l’articolo con mano R/L * Per ordinare l’articolo in confezione industriale
To order the R/L lock To order the lock in industrial packaging
2501 R CR0328S46 250 0 DCR0328S46
