P. 64

!
       SERRATURE PER PORTE BLINDATE                                        SERIE               SECURTINA/
       SAFETY DOOR LOCKS                         SECURTINA     Y           LINE   251 CILINDRO

       SOLO CATENACCIO, SENZA SCROCCO                          ONLY BOLT, NO LATCH
       Serratura con cuore intercambiabile a cilindro europeo 4 mandate corsa 40 mm, senza   Security lock with interchangeable European cylinder heart, 4 turns, bolts stroke 40 mm,
       scrocco, chiusura triplice.                             no latch and 3 locking points.
       Finitura zincata con catenacci in acciaio cromato.      Galvanized finishing with bolts in chromed steel.
       Disponibile anche con blocco SECURTINA.                 Also available with SECURTINA block.



                               Soddisfano la classe 7 (min 1 - max 7) secondo la norma
          C                    UNI ENV 12209:2005 in abbinamento alla piastra di protezione.
                R              According to UNI ENV 12209:2005 it meets class 7 (min 1 - max 7);
                               in combination with protection plate.







       FISSAGGIO PLANARE/LATERALE | PLANAR/LATERAL FIXING



                                                                   !
                                                              +
                           Y                               Y     SECURTINA
             cuore a cilindro/cylinder heart  con blocco Securtina/with Securtina block
          Apertura porta/Opening door            Apertura porta/Opening door
                                                                                   Sporgenza     Interasse
         D     R      S      L    g            D      R      S     L     g         pistoni (S)   Interspace
                                                                                   Projection
            *             *                        *            *                  bolts (S)                    *
       251 1 DCR0328CXX 251 1 SCR0328CXX  2050  251 1 DCR0328CT1 251 1 SCR0328CT1  2100  3 mm    28 mm          5
       251 1 DCR0628CXX 251 1 SCR0628CXX  2100  251 1 DCR0628CT1 251 1 SCR0628CT1  2150  6 mm    28 mm          5
       251 1 DCR1328CXX 251 1 SCR1328CXX  2198  251 1 DCR1328CT1 251 1 SCR1328CT1  2248  13 mm   28 mm          5
       251 1 DCR4328CXX 251 1 SCR4328CXX  2565  251 1 DCR4328CT1 251 1 SCR4328CT1  2605  43 mm   28 mm          5
       251 1 DCR0337CXX 251 1 SCR0337CXX  1950  251 1 DCR0337CT1 251 1 SCR0337CT1  2000  3 mm    37 mm          5
       251 1 DCR0637CXX 251 1 SCR0637CXX  2000  251 1 DCR0637CT1 251 1 SCR0637CT1  2050  6 mm    37 mm          5
       251 1 DCR1337CXX 251 1 SCR1337CXX  2098  251 1 DCR1337CT1 251 1 SCR1337CT1  2148  13 mm   37 mm          5
       251 1 DCR4337CXX 251 1 SCR4337CXX  2465  251 1 DCR4337CT1 251 1 SCR4337CT1  2515  43 mm   37 mm          5







                                                                             FRONTALE INOX
       FISSAGGIO AD INFILARE FRONTALE INOX | MORTICE FIXING INOX FRONTAL     INOX FRONTAL



       251 3 DCR0328CXX 251 3 SCR0328CXX  2514  251 3 DCR0328CT1 251 3 SCR0328CT1  2564  -       28 mm          5
       251 3 DCR0337CXX 251 3 SCR0337CXX  2414  251 3 DCR0337CT1 251 3 SCR0337CT1  2464  -       37 mm          5


     *  Per ordinare l’articolo con mano R/L  *  Per ordinare l’articolo in confezione industriale
       To order the R/L lock                   To order the lock in industrial packaging
       2511 R CR0328CXX                        251 0 DCR0328CXX







       SPECIALE BLOCCO SECURTINA                                                      ATTENZIONE! Installare il cilindro a serratura
       Si attiva solo in caso di estrazione forzata o rottura del cilindro, impedendo ai   aperta (catenacci dentro). In caso di estrazione
                                                                                      forzata del cilindro a serratura chiusa
       malintenzionati l’apertura della serratura e quindi dei catenacci. La serratura   (catenacci fuori), si attiva il blocco del cuore.
       rimane bloccata, evitando al ladro di entrare in casa.                         WARNING! Install the cylinder while the lock is
                                                                                      open (bolts inside). In case of forced extraction
       SPECIAL SECURTINA BLOCK                                                        of  the  cylinder  while the  lock  is  closed,  the
                                                                                      Securtina trap will automatically be activated.
       The device is activated only in case of forced extraction or break of the cylinder.
       In this way thieves cannot open the lock and relevant bolts.The lock remains   C.Q. TEST OK
       stuck thus avoiding intrusion into the apartment.
