SERRATURE PER PORTE BLINDATE SERIE BASIC GEAR/
SAFETY DOOR LOCKS Y G LINE 266 TOP GEAR

SOLO CATENACCIO, SENZA SCROCCO ONLY BOLT, NO LATCH
Serratura a cilindro europeo con movimento ad ingranaggi, corsa 30 mm senza scrocco, European cylinder lock with gear movement, bolts stroke 30 mm, no latch, 3 locking
chiusura triplice. points.
Finitura zincata con catenacci in acciaio cromato. Galvanized finishing with bolts in chromed steel.
A serratura chiusa la maniglia non sgancia lo scrocco. Also available in TOP GEAR version with reinforcement bolt system and double
A richiesta versione TOP GEAR con rinforzo sul catenaccio e doppio blocco SECURTINA. SECURTINA block.

P R

FISSAGGIO PLANARE/LATERALE | PLANAR/LATERAL FIXING

BASIC GEAR TOP GEAR

! !
+ +
Y Y SECURTINA SECURTINA
cuore a cilindro/cylinder heart con 2 blocchi Securtina/with 2 Securtina block
Apertura porta/Opening door Apertura porta/Opening door
Sporgenza Interasse
D R S L g D R S L g pistoni (S) Interspace
Projection
* * * * bolts (S) *
C C
con attacco Securemme/Securemme fixing con attacco Securemme/Securemme fixing
266 1 D CR0328CXX 266 1 S CR0328CXX 2100 266 1 D CR0328CT2 266 1 S CR0328CT2 2100 3 mm 28 mm 5
266 1 D CR0628CXX 266 1 S CR0628CXX 2150 266 1 D CR0628CT2 266 1 S CR0628CT2 2150 6 mm 28 mm 5
266 1 D CR1328CXX 266 1 S CR1328CXX 2248 266 1 D CR1328CT2 266 1 S CR1328CT2 2248 13 mm 28 mm 5
266 1 D CR4328CXX 266 1 S CR4328CXX 2618 266 1 D CR4328CT2 266 1 S CR4328CT2 2618 43 mm 28 mm 5
266 1 D CR0337CXX 266 1 S CR0337CXX 2000 266 1 D CR0337CT2 266 1 S CR0337CT2 2000 3 mm 37 mm 5
266 1 D CR0637CXX 266 1 S CR0637CXX 2050 266 1 D CR0637CT2 266 1 S CR0637CT2 2050 6 mm 37 mm 5
266 1 D CR1337CXX 266 1 S CR1337CXX 2148 266 1 D CR1337CT2 266 1 S CR1337CT2 2148 13 mm 37 mm 5
266 1 D CR4337CXX 266 1 S CR4337CXX 2518 266 1 D CR4337CT2 266 1 S CR4337CT2 2518 43 mm 37 mm 5

vite di testa/fixing with frontal screw vite di testa/fixing with frontal screw
T T
266 1 D CR0328TXX 266 1 S CR0328TXX 2208 266 1 D CR0328TT2 266 1 S CR0328TT2 2208 3 mm 28 mm 5
266 1 D CR0628TXX 266 1 S CR0628TXX 2258 266 1 D CR0628TT2 266 1 S CR0628TT2 2258 6 mm 28 mm 5
266 1 D CR1328TXX 266 1 S CR1328TXX 2356 266 1 D CR1328TT2 266 1 S CR1328TT2 2356 13 mm 28 mm 5
266 1 D CR4328TXX 266 1 S CR4328TXX 2726 266 1 D CR4328TT2 266 1 S CR4328TT2 2726 43 mm 28 mm 5
266 1 D CR0337TXX 266 1 S CR0337TXX 2108 266 1 D CR0337TT2 266 1 S CR0337TT2 2108 3 mm 37 mm 5
266 1 D CR0637TXX 266 1 S CR0637TXX 2158 266 1 D CR0637TT2 266 1 S CR0637TT2 2158 6 mm 37 mm 5
266 1 D CR1337TXX 266 1 S CR1337TXX 2256 266 1 D CR1337TT2 266 1 S CR1337TT2 2256 13 mm 37 mm 5
266 1 D CR4337TXX 266 1 S CR4337TXX 2626 266 1 D CR4337TT2 266 1 S CR4337TT2 2626 43 mm 37 mm 5

FRONTALE INOX
FISSAGGIO AD INFILARE FRONTALE INOX | MORTICE FIXING INOX FRONTAL INOX FRONTAL

C C
con attacco Securemme/Securemme fixing con attacco Securemme/Securemme fixing
266 3 D CR0328CXX 266 3 S CR0328CXX 2564 266 3 D CR0328CT2 266 3 S CR0328CT2 2564 - 28 mm 5
266 3 D CR0337CXX 266 3 S CR0337CXX 2464 266 3 D CR0337CT2 266 3 S CR0337CT2 2464 - 37 mm 5
vite di testa/fixing with frontal screw vite di testa/fixing with frontal screw
T T
265 3 D CR0328TXX 265 3 S CR0328TXX 2672 266 3 D CR0328TT2 266 3 S CR0328TT2 2672 - 28 mm 5
265 3 D CR0337TXX 265 3 S CR0337TXX 2572 266 3 D CR0337TT2 266 3 S CR0337TT2 2572 - 37 mm 5

* Per ordinare l’articolo con mano R/L * Per ordinare l’articolo in confezione industriale
To order the R/L lock To order the lock in industrial packaging
2661 R CR0328CXX 266 0 DCR0328CXX
