SERRATURE PER PORTE BLINDATE SERIE SECURTINA/
SAFETY DOOR LOCKS SECURTINA Y LINE 264 CILINDRO

MULTIFUNZIONE MULTIFUNCTIONAL
Serratura superiore a cilindro europeo 3 mandate corsa 30 mm e scrocco reversibile, chiusura triplice. European cylinder main lock, 3 turns, bolts stroke 30 mm and reversible latch, 3 locking points.
Serratura inferiore a cilindro europeo che aziona sulla prima mandata il limitatore d’apertura regolabile, European cylinder service lock that operates the adjustable limiting device with the first turn; 2 turns, bolt
2 mandate corsa 20 mm e scrocco. stroke 20 mm and independent latch.
Serrature indipendenti. Independent locks.
A richiesta la serratura inferiore blocca la serratura superiore (serrature dipendenti). Also available with interconnected locks: the service lock can block the main lock.
Finitura zincata con catenacci in acciaio cromato. Galvanized finishing with bolts in chromed steel.
A richiesta anche con blocco SECURTINA. Also available with SECURTINA block.
A serratura chiusa la maniglia non sgancia lo scrocco. When locked, the handle does not unhook the latch.
Possibilità fissaggio rosetta maniglia con viti passanti interasse 38 mm. It is possible to fix the handle escutcheon with 38 mm interspace through screw.
Soddisfano la classe 7 (min 1 - max 7) secondo la norma
UNI ENV 12209:2005 in abbinamento alla piastra di protezione.
B P R 5 COMPLIENCES WITH EUROPEAN REGULATION According to UNI ENV 12209:2005 it meets class 7 (min 1 - max 7);
EN 12209:2005 in combination with protection plate.
FISSAGGIO PLANARE/LATERALE | PLANAR/LATERAL FIXING

!
+
Y Y SECURTINA
cuore a cilindro/cylinder heart con blocco Securtina/with Securtina block
Apertura porta/Opening door Apertura porta/Opening door
Sporgenza Interasse
D R S L g D R S L g pistoni (S) Interspace
Projection
* * * * bolts (S) *
C C
con attacco Securemme/Securemme fixing con attacco Securemme/Securemme fixing
264 1 D CR0328CXX 264 1 S CR0328CXX 2746 264 1 D CR0328CT1 264 1 S CR0328CT1 2854 3 mm 28 mm 5
264 1 D CR0628CXX 264 1 S CR0628CXX 2796 264 1 D CR0628CT1 264 1 S CR0628CT1 2904 6 mm 28 mm 5
264 1 D CR1328CXX 264 1 S CR1328CXX 2894 264 1 D CR1328CT1 264 1 S CR1328CT1 3002 13 mm 28 mm 5
264 1 D CR4328CXX 264 1 S CR4328CXX 3264 264 1 D CR4328CT1 264 1 S CR4328CT1 3372 43 mm 28 mm 5
264 1 D CR0337CXX 264 1 S CR0337CXX 2646 264 1 D CR0337CT1 264 1 S CR0337CT1 2754 3 mm 37 mm 5
264 1 D CR0637CXX 264 1 S CR0637CXX 2696 264 1 D CR0637CT1 264 1 S CR0637CT1 2804 6 mm 37 mm 5
264 1 D CR1337CXX 264 1 S CR1337CXX 2794 264 1 D CR1337CT1 264 1 S CR1337CT1 2902 13 mm 37 mm 5
264 1 D CR4337CXX 264 1 S CR4337CXX 3164 264 1 D CR4337CT1 264 1 S CR4337CT1 3272 43 mm 37 mm 5
vite di testa/fixing with frontal screw vite di testa/fixing with frontal screw
T T
264 1 D CR0328TXX 264 1 S CR0328TXX 2746 264 1 D CR0328TT1 264 1 S CR0328TT1 2854 3 mm 28 mm 5
264 1 D CR0628TXX 264 1 S CR0628TXX 2796 264 1 D CR0628TT1 264 1 S CR0628TT1 2904 6 mm 28 mm 5
264 1 D CR1328TXX 264 1 S CR1328TXX 2894 264 1 D CR1328TT1 264 1 S CR1328TT1 3002 13 mm 28 mm 5
264 1 D CR4328TXX 264 1 S CR4328TXX 3264 264 1 D CR4328TT1 264 1 S CR4328TT1 3372 43 mm 28 mm 5
264 1 D CR0337TXX 264 1 S CR0337TXX 2646 264 1 D CR0337TT1 264 1 S CR0337TT1 2754 3 mm 37 mm 5
264 1 D CR0637TXX 264 1 S CR0637TXX 2696 264 1 D CR0637TT1 264 1 S CR0637TT1 2804 6 mm 37 mm 5
264 1 D CR1337TXX 264 1 S CR1337TXX 2794 264 1 D CR1337TT1 264 1 S CR1337TT1 2902 13 mm 37 mm 5
264 1 D CR4337TXX 264 1 S CR4337TXX 3164 264 1 D CR4337TT1 264 1 S CR4337TT1 3272 43 mm 37 mm 5

FRONTALE INOX
FISSAGGIO AD INFILARE FRONTALE INOX | MORTICE FIXING INOX FRONTAL INOX FRONTAL

C C
con attacco Securemme/Securemme fixing con attacco Securemme/Securemme fixing
264 3 D CR0328CXX 264 3 S CR0328CXX 3056 264 3 D CR0328CT1 264 3 S CR0328CT1 3164 - 28 mm 5
264 3 D CR0337CXX 264 3 S CR0337CXX 2956 264 3 D CR0337CT1 264 3 S CR0337CT1 3064 - 37 mm 5
vite di testa/fixing with frontal screw vite di testa/fixing with frontal screw
T T
264 3 D CR0328TXX 264 3 S CR0328TXX 3056 264 3 D CR0328TT1 264 3 S CR0328TT1 3164 - 28 mm 5
264 3 D CR0337TXX 264 3 S CR0337TXX 2956 264 3 D CR0337TT1 264 3 S CR0337TT1 3064 - 37 mm 5

* Per ordinare l’articolo con mano R/L * Per ordinare l’articolo in confezione industriale A richiesta serrature dipendenti, pag 52
To order the R/L lock To order the lock in industrial packaging Also available with interconnected locks, see page 52
2641 R CR0328CXX 264 0 DCR0328CXX 5 264 6 DCR0328CXX

264 5 DCR0328CXX
