PROTECTOR E COORDINATI FORTEZZA
PROTECTOR AND KITS

Codice Descrizione H I Finitura
Code Description Finishing g
4250XZB15M5 Protector Ø 50 mm in acciaio carbonitrurato 15 38 ZB 10-60 156
4250XZB22M5 e zinco tropicalizzato. Durezza > 60 HRC 22 38 ZB 10-60 204
4250XZB25M5 resistente al trapano. Guidachiave in acciaio 25 38 ZB 10-60 250 Y
4250XZB25A5 carbonitrurato. 25 31 ZB 10-60 250
Protector Ø 50 mm in carbonitrided steel and ATRA/DIERRE
galvanized zinc. Hardened > 60 HRC resistant
ZB
to drill. Key-guide in carbonitrided steel.
4252XZB25M5 Protector FORTEZZA M8 Ø50 mm 25 38 ZB NEW 10-60 250
Protector FORTEZZA M8 Ø50 mm
4150XF1 Cover per protector Fortezza disponibile in varie finiture F1 10-120 9
4150XF3 Cover for protector Fortezza available in different finishings F3 10-120 9
4150XF4 F4 10-120 9 Y
4150XF5 F5 10-120 9
4150XPV F1 F3 F4 F5 PV 10-120 24
4150XOB OB 10-120 24
4150XOL OL 10-120 24
4150XCL PV OB OL CL CS CL 10-120 24
4150XCS CS 10-120 24
Base alluminio | Aluminium material
Base ottone | Brass material
Una volta assemblato il protector al cover completare il montaggio con la scelta delle piastrine in abbinamento
Once protector and cover assembled complete with the escutcheons in combination

Codice Descrizione H Spessore (S) mm Finitura
Code Description Thickness (S) mm Finishing g
4330XF113 Piastrina antistrappo in lamiera imbutita 13 8 F1 10-60 24
4330XF313 predisposta per protector Ø 50 mm h 15 13 8 F3 10-60 24
4330XF413 Tear-proof escutcheon in bended steel 13 8 F4 10-60 24 Y
4330XPV13 arranged for protector Ø 50 mm h 15 13 8 PV 10-60 78
4330XOL13 13 8 OL 10-60 78
4330XCL13 13 8 CL 10-60 78
4330XCS13 13 8 CS 10-60 78
4330XF122 per protector Ø 50 mm h 22 22 8 F1 10-60 30 S
4330XF322 for protector Ø 50 mm h 22 22 8 F3 10-60 30
4330XF422 22 8 F4 10-60 30
4330XPV22 22 8 PV 10-60 96
4330XOL22 22 8 OL 10-60 96
4330XCL22 22 8 CL 10-60 96
4330XCS22 22 8 CS 10-60 96
4330XPV27 per protector Ø 50 mm h 25 27 4 PV 10-60 104
4330XOL27 for protector Ø 50 mm h 25 27 4 OL 10-60 104
4330XCL27 27 4 CL 10-60 104
4330XCS27 27 4 CS 10-60 104

F1 F3 F4 PV OL CL CS Base alluminio | Aluminium material
Base Acciaio | Steel material

4320KF1 Piastrina 62x82 mm, foro 50 mm, completa F1 10-120 20
4320KF3 di supporto plastico. Da abbinare a protector F3 10-120 20
4320KF4 universale Ø 50 mm art. 4250 e cover art. 4150 F4 10-120 20 Y
4320KOL Escutcheon 62x82 mm, hole 50 mm with OL 10-120 34
4320KCL plastic support. To combine with protector CL 10-120 34
4320KCS Ø 50 mm art. 4250 and cover art. 4150 CS 10-120 34

Base alluminio | Aluminium material
F1 F3 F4 OL CL CS Base ottone | Brass material

4370KOL Piastrina rettangolare 62x82 mm, foro 50 OL 10-120 34
4370KCL mm, completa di supporto plastico. CL 10-120 20
4370KCS Da abbinare a protector universale Ø 50 mm CS 10-120 20 Y
art. 4250 e cover art. 4150
Rectangular escutcheon 62x82 mm, hole 50 mm
with plastic support. To combine with protector
Ø 50 mm art. 4250 and cover art. 4150
Base alluminio | Aluminium material
OL CL CS Base ottone | Brass material

Tutti i quantitativi saranno aumentati al lotto minimo di 10 pz e relativi multipli
All quantities will be increased to minimum lot of 10 pcs and multiples
