ACCESSORI  -  Deviatori
       ACCESSORIES  -  Switches

       Codice      Descrizione
       Code        Description                                                g
       AT2172XZB   Dima di foratura per tubolari 30x40 mm per art.   -       -
                   2172,2173,2174 HERCULES
                   Mould to hole tubes 30x40 mm for art. 2172, 2173, 2183
                   HERCULES
          ZB















       L - Larghezza | Width       CH - Punti di chiusura | Closing points   A - Corsa A | Stroke A   B - Corsa B | Stroke B



       Codice      Descrizione                        L    CH   A    B
       Code        Description                                                   g
       2183XAI2525  Deviatore HERCULES H.174xL.40xS.19 c/catenaccio  37  2  25  24  15  747
                   basculante corsa aste 24 mm frontale IN OX 310x25x3 mm
                   HERCULES switch H.174xL.40xS.19 with tilting deadbolt
                   rod stroke 24 mm stainless steel front 310x25x3 mm

         AI




















       2184XAI23AK  Deviatore HERCULES H.174xL.40xS.19 c/catenaccio   37  2  18,5  24  15  788
                   a gancio lamellare bicomponente corsa aste 24 mm
                   frontale INOX 310x25x3 mm
                   HERCULES switch H.174xL.40xS.19 with two-component
                   lamellar hook bolt stroke 24 mm stainless steel front
                   310x25x3 mm

         AI
