PROTECTOR E COORDINATI SERIE F-R-Q
PROTECTOR AND KITS LINE

Codice Descrizione Finitura
Code Description Finishing g
4380KF1 Piastrina F interna/esterna 66x88x10 con foro Ø46 completa di F1 10-120 20
4380KF3 supporto plastico. Per utilizzare con gli inserti Ø46 mm (4000-4001- F3 10-120 20
4380KF4 4010-4011-4012-4015-4016-4018-4020-4021-4030) e/o protectors con F4 10-120 20 D Y
4380KF5 cover serie PROTECNO e ai protectors serie BLINDO Ø46 mm ordinare a F5 * 10-120 51
4380KCL parte l’ inserto adattatore IN4380XBK. CL 10-120 51
4380KCS Internal/external escutcheon F 66x88x10 with hole Ø46 complete with CS 10-120 51
4380KOL plastic support. Please order separately IN4380XBK adapter insert to OL Ø46
use with Ø46 mm inserts (4000-4001-4010-4011-4012-4015-4016-4018- 88
4020-4021-4030) and/or protectors with PROTECNO line cover and with
BLINDO line Ø46 mm protectors.
Base alluminio | Aluminium material 66 11
F1 F3 F4 F5 OL CL CS Base ottone | Brass material

4400KF1 Piastrina R, interna/esterna, Ø70 con foro Ø46, comprensiva F1 10-120 20
4400KF3 di supporto in plastica. Da abbinare a tutti gli inserti Ø46 mm F3 10-120 20
4400KF4 (4000-4001-4010-4011-4012-4015-4016-4018-4020-4021-4030) F4 10-120 20 D Y
4400KF5 e/o con protezioni con cover PROTECNO Ø46 4224 e BLINDO Ø46 F5 * 10-120 20
4400KOL 4246/4260. OL 10-120 51
4400KCL Internal/external escutcheon R Ø70 with hole Ø46, including plastic CL 10-120 51
4400KCS support. To combine with all Ø46 mm inserts (4000-4001-4010- CS 10-120 51
4011-4012-4015-4016-4018-4020-4021-4030) and/or with protectors
with cover PROTECNO Ø46 4224 and BLINDO Ø46 4246/4260.
4405X** Piastrina ROUND Ø70x10 da abbinare a FORZIERE Ø 46 mm
(senza supporto plastico PL4405 da ordinare a parte).
ROUND plate Ø70x10 to be combined with FORZIERE Ø 46 mm
(without plastic support PL4405 to be ordered separately).
Base alluminio | Aluminium material ** scelta tra le finiture disponibili
F1 F3 F4 F5 OL CL CS Base ottone | Brass material ** choose among the finishings available

4350KF1 Piastrina Q interna/esterna 62x82x6 con foro Ø46, completa di F1 10-120 25
4350KF3 supporto plastico. Da abbinare a tutti gli inserti Ø46 mm (4000-4001- F3 10-120 25
4350KF4 4010-4011-4012-4015-4016-4018-4020-4021-4030) e/o a protectors F4 10-120 25 D Y
4350KF5 con cover PROTECNO Ø46 4224 e BLINDO Ø46 4246/4260. F5 10-120 25
4350KOB OB * 10-120 43
4350KOL Internal/external escutcheon Q 62x82x6 with hole Ø46, including OL 10-120 43
4350KCL plastic support. To combine with all Ø46 mm inserts (4000-4001-4010- CL 10-120 43
4350KCS 4011-4012-4015-4016-4018-4020-4021-4030) and/or with protectors CS 10-120 43
with cover PROTECNO Ø46 4224 and BLINDO Ø46 4246/4260.
Base alluminio | Aluminium material
F1 F3 F4 F5 OL CL CS Base ottone | Brass material
4555KF1 Placca Q interna/esterna 62x170x6 con foro Ø46, completa F1 10-60 64
4555KF4 di supporto plastico ed adattatori per collo maniglia F4 10-60 64
4555KF5 Ø15,16,18 e niplex M10. Da abbinare ad inserti Ø46 mm a F5 10-60 64 D
4555KOB doppia mappa (4000-4001) e/o a protector a doppia mappa OB * 10-60 104
4555KOL 4224 con cover. OL 10-60 104
4555KCL Internal/external plate Q 62x170x6 with hole Ø46, including CL 10-60 104
4555KCS plastic support and adapters for handle Ø15,16,18 and niplex CS 10-60 104
M10. To combine with double ward inserts Ø46 mm (4000-
4001) and/or with double ward protector 4224 and cover.

Base alluminio | Aluminium material
F1 F4 F5 OB OL CL CS Base ottone | Brass material

4556KF1 Placca Q interna/esterna 62x170x6 con foro Ø46, completa F1 10-60 64
4556KF4 di supporto plastico ed adattatori per collo maniglia F4 10-60 64
4556KF5 Ø15,16,18 e niplex M10. Da abbinare ad inserti Ø46 mm per F5 10-60 64 Y
4556KOB cilindro europeo (4010-4011-4012-4015) e/o a protector OB * 10-60 104
4556KOL BLINDO Ø46 4246/4260 con cover. OL 10-60 104
4556KCL Internal/external plate Q 62x170x6 with hole Ø46, including CL 10-60 104
4556KCS plastic support and adapters for handle Ø15,16,18 and niplex CS 10-60 104
M10. To combine with european cylinder inserts Ø46 mm
(4010-4011-4012-4015) and/or with Ø46 protector BLINDO
4246/4260 and cover.

Base alluminio | Aluminium material
F1 F4 F5 OB OL CL CS Base ottone | Brass material

* Tutti i quantitativi saranno aumentati al lotto minimo di 10 pz e relativi multipli
* All quantities will be increased to minimum lot of 10 pcs and multiples
