CILINDRI NEW
CYLINDERS EVOK22/EVOK22 TOP

SERIE PREDISPOSIZIONE POMOLO | KNOB PREDISPOSITION LINE
Serie Finitura Finitura A B C
Line Finishing OL Finishing CS g
3220-Q 3220QOL30301X5 3220QCS30301X5 60 30 30 10 - 20 336

3220-Q 3220QOL30351X5 3220QCS30351X5 65 30 35 10 - 20 351

3220-Q 3220QOL30401X5 3220QCS30401X5 70 30 40 10 - 20 366
K
3220-Q 3220QOL30451X5 3220QCS30451X5 75 30 45 10 - 20 381

3220-Q 3220QOL30501X5 3220QCS30501X5 80 30 50 10 - 20 396

3220-Q - 3220QCS30551X5 85 30 55 10 - 20 411

3220-Q - 3220QCS30601X5 90 30 60 10 - 20 426 52 Ø8
B
3220-Q - 3220QCS30651X5 95 30 65 10 - 20 441 C

3220-Q - 3220QCS30701X5 100 30 70 10 - 20 456
A
3220-Q - 3220QCS30801X5 110 30 80 10 - 20 486

3220-Q - 3220QCS30851X5 115 30 85 10 - 20 501

3220-Q - 3220QCS30901X5 120 30 90 10 - 20 516

SERIE PREDISPOSIZIONE POMOLO | KNOB PREDISPOSITION LINE MODULARE
Serie Finitura Finitura Finitura A B C
Line Finishing OL Finishing CS Finishing BK NEW g MODULAR
322T-Q 322TQOL31311X5 322TQCS31311X5 322TQBK31311X5 62 31 31 10 - 40 336

322T-Q 322TQOL31361X5 322TQCS31361X5 322TQBK31361X5 67 31 36 10 - 40 351

322T-Q 322TQOL31411X5 322TQCS31411X5 322TQBK31411X5 72 31 41 10 - 40 366
KA TAN
DEM
322T-Q 322TQOL31461X5 322TQCS31461X5 322TQBK31461X5 77 31 46 10 - 40 381 K
322T-Q 322TQOL31511X5 322TQCS31511X5 322TQBK31511X5 82 31 51 10 - 40 396

322T-Q 322TQOL31561X5 322TQCS31561X5 322TQBK31561X5 87 31 56 10 - 40 411
52 Ø8
322T-Q 322TQOL31611X5 322TQCS31611X5 322TQBK31611X5 92 31 61 10 - 40 426 B

322T-Q 322TQOL31661X5 322TQCS31661X5 322TQBK31661X5 97 31 66 10 - 40 441 C

322T-Q 322TQOL31711X5 322TQCS31711X5 322TQBK31711X5 102 31 71 10 - 40 456
A
322T-Q 322TQOL31761X5 322TQCS31761X5 322TQBK31761X5 107 31 76 10 - 40 486

322T-Q 322TQOL31811X5 322TQCS31811X5 322TQBK31811X5 112 31 81 10 - 40 501

322T-Q 322TQOL31861X5 322TQCS31861X5 322TQBK31861X5 117 31 86 10 - 40 516 DISPONIBILE IN TUTTE LE MISURE
FINO A MAX 200 mm
AVAILABLE IN ALL SIZES
322T-Q 322TQOL31911X5 322TQCS31911X5 322TQBK31911X5 122 31 91 10 - 40 525 UP TO MAX 200 mm
Esecuzioni KA = stessa combinazione e possibilità di esecuzioni speciali consultabili a pag. 234
KA executions= cylinders with same combination; possibility of special executions at page 234
