CILINDRI
CYLINDERS K2

SERIE POMOLO REMOVIBILE | REMOVABLE KNOB LINE
Serie Finitura Finitura A B C g
Line Finishing OL Finishing CS
3200-P 3200POL30301X5 3200PCS30301X5 60 30 30 10 - 50 384 TAN
KA DEM
3200-P 3200POL35301X5 3200PCS35301X5 65 35 30 10 - 50 397 K

3200-P 3200POL35351X5 3200PCS35351X5 70 35 35 10 - 50 412
3200-P - 3200PCS35401X5 75 35 40 10 - 50 397

3200-P 3200POL35451X5 3200PCS35451X5 80 35 45 10 - 50 422
3200-P 3200POL40301X5 3200PCS40301X5 70 40 30 10 - 50 412

3200-P 3200POL40351X5 3200PCS40351X5 75 40 35 10 - 50 397
3200-P 3200POL40401X5 3200PCS40401X5 80 40 40 10 - 50 422

3200-P 3200POL40451X5 3200PCS40451X5 85 40 45 10 - 50 450
3200-P 3200POL40501X5 3200PCS40501X5 90 40 50 10 - 50 478 B

3200-P 3200POL45301X5 3200PCS45301X5 75 45 30 10 - 50 397 C
3200-P 3200POL45351X5 3200PCS45351X5 80 45 35 10 - 50 422
A
3200-P 3200POL45451X5 3200PCS45451X5 90 45 45 10 - 50 478
3200-P 3200POL50301X5 3200PCS50301X5 80 50 30 10 - 50 401

3200-P 3200POL50401X5 3200PCS50401X5 90 50 40 10 - 50 478
3200-P 3200POL50501X5 3200PCS50501X5 100 50 50 10 - 50 516

3200-P 3200POL55351X5 3200PCS55351X5 90 55 35 10 - 50 478
3200-P 3200POL55451X5 3200PCS55451X5 100 55 45 10 - 50 516

3200-P 3200POL60301X5 3200PCS60301X5 90 60 30 10 - 50 478
3200-P 3200POL60401X5 3200PCS60401X5 100 60 40 10 - 50 516

SERIE POMOLO REMOVIBILE | REMOVABLE KNOB LINE
Serie Finitura Finitura A B C g
Line Finishing OL Finishing CS
3200-Q 3200QOL30301X5 3200QCS30301X5 60 30 30 10 - 50 366
KA TAN
K DEM
3200-Q 3200QOL30351X5 3200QCS30351X5 65 30 35 10 - 50 382
3200-Q 3200QOL30401X5 3200QCS30401X5 70 30 40 10 - 50 396
3200-Q 3200QOL30451X5 3200QCS30451X5 75 30 45 10 - 50 410
Ø8
3200-Q 3200QOL30501X5 3200QCS30501X5 80 30 50 10 - 50 427 B
C
3200-Q 3200QOL30551X5 3200QCS30551X5 85 30 55 10 - 50 430 52

3200-Q 3200QOL30601X5 3200QCS30601X5 90 30 60 10 - 50 497
A
3200-Q - 3200QCS30651X5 95 30 65 10 - 50 497

3200-Q 3200QOL30701X5 3200QCS30701X5 100 30 70 10 - 50 489
3201= cilindri con CAM a 30° a sinistra per serrature sinistra serie 27 elettromeccanica (vedi pag. 117) | 3201= cylinders with left CAM 30° for electromechanical left lock line 27 (see page 117)
Esecuzioni KA = stessa combinazione e possibilità di esecuzioni speciali consultabili a pag. 234
KA executions= cylinders with same combination; possibility of special executions at page 234

164
